gridfinity-catalog

This is a Catalog of Gridfinity designs and other relevant resources. Your pull requests are welcome!

Introduction

In April of 2022, Zack Freedman announced Gridfinity to the world in this video:

Gridfinity: Your Ultimate Modular Workshop is FREE!

Using a design based on earlier work by Alexandre Chappel, Zack designed a modular system that uses a gridded baseplate that accomodates blocks (also referred to as boxes or bins) sized to fit into one or more grid cells. After the publication of Zack's video, other designers began to adopt existing designs and to create new ones. This page is an attempt to catalog as many Gridfinity resources as possible.

In July of 2022, Zack published a follow-on video to highlight a plethora of community designs:

3D Print a Modular Toolbox, Soldering Station, and More!

Getting Started with Gridfinity

  • Pick a baseplate
  • Pick some boxes
  • Print
  • Use
  • Share
  • Learn about parameterization and customization

You can also start with the Gridfinity Master Collection .

Baseplates

Description Sizes Variants Format Date Added
Baseplate 3x3.5 3x3.5 1 STL 2022-07-21
Baseplates 1x2 - 7x7 55 STL 2022-06-12
Baseplates (OpenSCAD Customizable) - OpenSCAD 2022-06-12
Basic Gridfinity Baseplates (CadQuery Customizable) 1x1 - 10x10 22 CadQuery 2022-06-12
Baseplates with Pressure Fit Magnets 1x1 - 7x7 130 STL,F360,STP 2023-03-30
Base with Snap Connectors 1x1 - 7x7 30 STL,STP 2023-03-30
ClickFinity Baseplate - No Magnets 1x1 - 7x7 49 STL,F3D 2023-05-16
Clickfinity Refined Baseplate 1x1-5x7 30 STL 2023-07-17
ClickPlate - Secure any existing Gridfinity block without costly neodymium magnets and thick bin bottoms for the magnet holes F3D available - Fusion 360, STL 2023-03-19
CR10-CR10S Printer-Mounted Baseplate 1x1 1 STL 2022-07-25
DDD Wall Control System 2x2-5x9 15 STL
Ender 3 Baseplate Sidecar 1x1 1 STL
Ender 3 Power ledge Baseplate 2x1 1 STL 2022-07-25
Ender 3 Pro and V2 Baseplate double 2x1 1 STL 2022-07-25
Ikea Alex Wide Drawers 3x5-5x5 3 3MF 2024-01-23
Ikea Skadis Baseplate - baseplates that attach to Ikea Skadis pegboards 1x2 - 2x7 12 STL 2022-09-06
Improved Baseplate 2x2 - 6x6 8 3MF 2022-06-12
Jesh Baseplates for Crappy Printers 1x1 - 6x6 19 STEP 2023-05-16
Lasercut Base 7x12 1 F3D 2023-05-16
Magnet Light Baseplate 1x1 - 8x8 36 STL/F3D 2022-10-30
Minimal Baseplate 4x4 + Customizable 1 STL, F3D 2022-08-12
Modular Gridfinity Drawers 2x3-3x5 48 STL,STP 2024-03-12
Parametric Wall Control Baseplates 4x1 - 5x6 18 3MF 2022-06-12
Pegboard 1x4 - 3x4 3 STL 2022-06-12
Printer-Mounted Baseplates - Baseplates that mount on various 3D printers 1x1 6 STL 2022-06-12
Screw Together Baseplate 1x1 - 7x7 28 STL 2022-10-27
Sideless Platforms 1x1 - 5x5 15 STL 2022-06-18
Snap Together Baseplate with Captured Magnets 2x1 - 5x5 20 3MF, F3D, STEP 2023-01-09
Superlight Baseplates 1x3 - 5x5 14 STL 2023-10-07
Support-less Weighted Baseplates (CadQuery Customizable) 1x1 - 7x7 13 STL 2022-06-12
Thin Baseplate with Magnets 2x2 - 6x6 15 STL 2022-10-27
Thinner Minimal Baseplate 4x4 + Customizable 1 STL, F3D 2022-08-12
Under-Desk Drawer 4x4 1 STL + STEP 2022-09-21
Under-Desk Drawer half-and-half combo 2x4 1 STL 2024-02-14
VESA Shelf and VESA Shelf Back 1x3 1 STL 2022-12-06
Vertical Baseplate 4x3 1 STL/F3D 2022-07-25
Voron printer (2020 extrusion) Baseplate 1x1 1 STL/F3D 2022-07-25
Wall Rack 1x4 1 STL 2022-06-17
Weighted Baseplate 5x7.stl 5x7 1 STL 2022-07-22
Weighted Baseplate 7x7.stl 7x7 1 STL 2022-07-22

Blocks

Description Sizes Variants Format Date Added
1/4" Drive Long Socket with Magnetic Base 2x2 1 STP 2023-12-26
18650 holder 1x1 1 3MF 2022-07-25
42mm Bottle Holder 1x1 1 STL 2022-09-26
3D Printing Accessories 1x1, 1x3 7 STL 2022-06-16
8 AA batteries storage 2x1 1 STL/F3D 2022-07-25
9V Battery Holder 1x1, 1x2 2 3MF 2022-07-01
AA Battery Holder 1x2 1 STL 2022-06-12
AAA Battery Container 1x1, 1x2 2 STL 2022-07-01
Acrylic Paint Holder 1x3 1 STL 2022-07-21
Adjustable Jumper Wire Comb 1x1 2 elements STL 2022-07-25
Adjustable Light 2x2 1 STL 2023-01-06
Allen Key Metric 1x1 1 STL 2022-06-12
Angled Bin 4x2 1 + 4 inserts STL 2022-09-04
Audio Jack Holder (3.5mm & 6.35mm) 1x1 1 STL 2022-07-11
Bambu X1C Nozzles 1x1 1 STL 2022-09-04
Basic Undivided Gridfinity Boxes 1x1 - 5x5 28 CadQuery 2022-06-12
Battery Box: CR2032/CR2016, 357/303/SR44 and A23/MN21/AAA slots 1x1 1 3MF/F3D 2022-07-25
Battery trays 1x1,1x3,2x2 Many STL 2024-02-14
Battery holders, stackable 1x1 - 2x2 Many STL 2024-02-14
Battery holders, stackable (remix) (source) 2x2 4 OpenSCAD,STL 2024-02-14
Battery holders (AGxx), stackable 1x1 - 2x2 Many STL 2024-02-14
Battery holders (CRxxxx), stackable 1x1 - 2x2 Many STL 2024-02-14
Battery holders (LRx), stackable 1x1 - 2x2 Many STL 2024-02-14
Big Storage Boxes 4x1 - 5x5 36 STL 2022-06-25
Bins with Pressure Fit Magnets 1x1 - 7x7 1508 STL,F360,STP 2023-03-30
Bins with Cover (1x1) 1x1 17 STL 2024-02-14
Bins with Cover (2x1) 2x1 24 STEP,STL 2024-02-14
Bins with Lids (parametric) (source) 1x1-2x2 + Customizable 58 OpenSCAD,STL 2024-02-14
Bins with Swappable Labels 1x1-3x2 32 STL,3MF 2024-04-29
Bolt Sorter 1x2 1 STL 2022-09-04
Bottle 1x1 4 STL 2022-06-17
Bottle Cap 1x1 1 STL 2022-07-25
Bowls 1x1,1x2,1x4,2x2 4 STL 2023-04-09
Breadboard Holders 1x2, 2x2, 2x4 3 F3D + STL 2022-09-04
Breadboard Bins (source) 2x4 - 4x4, customizable 24 OpenSCAD,STL 2024-02-14
Cable Tray 1x3 1 STL 2022-08-16
Caliper Holder 1x2 1 STL 2022-06-16
Can Holder 2x2 1 STL 2022-07-21
Case for Ferrules and Crimp Tool 2x5 1 STL 2024-03-19
Case for Scalpels 4x2 1 F3D + STL 2022-09-04
Celtic Knot Bin 1x1 (std, ext), 1x2 (std, ext), 2x2 (std, ext) 1 STL 2023-03-15
Chalk Holder 1x1 1 STL 2022-09-04
Chisel Holder 4x7 1 STL 2022-09-04
Cigfinity Pack Dispenser 3x2 2 STL 2022-09-04
CNC Tool Holders 1x2, 2x2, 3x3 4 STL 2022-07-19
Coin Cell Battery Holder 1x1, 1x2 1 STL 2022-06-12
Collet Holder 1x3, 2x3 1 STL 2022-07-19
Collet Holder for CNC 2x2, 2x3 2 STL 2022-07-19
Condom Dispenser 2x2 1 STL 2024-01-27
Credit Cards 2x2 1 STL 2022-07-18
Cutlery Low Profile Bins 1x6,1x6.5 2 STL 2024-04-01
Deburring Tool, countersink, and spare blades 1x2 1 STL 2022-07-20
Dense 9 Full SD & 9 Micro SD Card Storage 1x1 1 STL 2022-07-25
Diamond Needle File kit 1x1 1 STL 2022-07-20
Dice Holder for DnD and other TTRPG 1x3 7 STL 2022-10-26
Divider Bins 1x1 - 5x1 51 variants STL 2022-06-12
Divided Boxes (CadQuery Customizable) 1x1 - 5x5 37 STL 2022-06-13
Divider Box for Breadboard Jumper Wires 2x5 1 STL 2022-07-21
Divided Vase Bins with Labels 1x1-1x5 120 STL 2023-02-26
Door'ed Container 2x2 1 STL 2022-07-18
Drawers 2x3,4x6 6 STL 2022-07-21
Drawers for Lack Enclosures 3x4 3 3MF 2024-02-14
Dremel Bit 3x2 1 STL 2022-06-19
Dremel Box Organizer - 17 elements STL 2022-07-19
Drill Caddy 2x2 1 STEP 2022-09-04
Economical Plain Storage Bins 1x3-6x6 84 STL 2023-10-30
Engineer SS-02 Solder Sucker 1x1 1 STL 2022-07-25
Epson Label Cartridge Holder 2x2, 2x4 4 STL 2022-07-20
Filled Bins Full Height No Lip 0.5x0x5 - 7x7 3MF 2023-03-23
Filled-In Boxes for Customization 1x1-7x7 39 STL 2023-03-20
Flip-Top Container 1x3 1 STL 2022-07-18
Funnel 1x1 1 STL 2022-07-19
Fusion360 Templates Varies 3 F3D 2022-09-26
Generic Upright Holder 2x2 1 STL 2024-01-01
Glasses (3x) Stand 1x3 1 STL 2022-07-22
Glue Stick 1x1 1 OpenSCAD 2022-06-12
Gorilla Glue Holder 1x1 1 STL 2022-07-01
GoPro Holder 1x2 1 STL 2022-09-04
Half Boxes 0.5x1 - 0.5x3 10 STL 2022-09-19
Height Tool 1x1 1 STP + 3MF 2023-03-15
Helping Hand 1x1 1 STL 2022-07-25
Helping Hands Base 1x1 1 STL 2022-09-08
Hex Baskets 1x1-3x5 21 STL 2022-06-12
Hex Bit Holder 1x3 2 STL 2022-07-08
Hex Bit Storage with Tray, 2x2 2x2 2 STL 2022-06-12
Hex Bit Storage with Tray, 2x4 2x4 1 STL 2022-06-18
Hinged Box 1x1, 1x2 2 STL 2024-01-16
Hobby Knife Stand 1x2 1 STL 2022-09-06
Hyper Tough 20-piece Ratchet Holder 4x3 1 STL,F3D 2023-05-29
iFixit Mako + ES121 Screwdriver Holders 1x4,2x4 3 STL 2022-07-19
Jumbo Glue Stick Holder 1x1 1 STL 2022-06-12
Jumper Wire Holder 1x1 1 STL 2022-07-19
Kitchen Bag Bins - Ikea Istad and More 1x6-2x4 3 STL 2024-04-01
Kitchen Caddy Jr. 2x1 1 STL 2022-09-04
Kitchen Caddy Sr. 4x3 1 + 3 trays STL 2022-09-04
Label Slot Bins 1x1-4x2 20 STL 2024-01-09
LCD Display Holder 2x1 1 STL 2022-09-04
Lite Economical Plain Storage Bins 1x1 - 6x6 84 STL 2023-10-03
Lite Ultra Boxes 168 1x1 - 5x5 STL,F3D 2023-05-16
Lithium Button Battery Beast 1x3 1 STL 2022-07-20
Long n' Tall Drawer 1x3 2 parts STL 2022-09-04
Material Swatches holder (source) 1x1 - 2x4 + Customizable 7 OpenSCAD,STL 2024-02-14
Mechanical Keyboard Keycap Storage Trays 5x5, 5x7 4 STL 2022-09-04
Mechanical Pencil (Staedtler Micro 775) Holder 2x1 1 STL, F3D 2023-06-04
M6 Washer Holder 1x1 1 F3D + STL 2022-09-04
MicroSD combo bin 1x1 1 STL 2024-02-14
Milk Crate Box + Base 1x1 3 STL 2024-06-03
Minifig Display Base 1x1, 3x4 2 STL, STEP 2023-01-09
Minifinity Bin Collection 1x1-4x2 9 STL 2022-07-29
Mintion Beagle Cam Mount 2x2 2 elements STL 2022-07-25
Model Paint Holder 3x3 1 STL 2022-09-04
Modular Drawer System 3x5 1 STL 2022-12-06
Mounted Hanging Trash Can 2x2 2 elements STL 2022-07-25
Needle File Set Holder (Draper 6 Piece Diamond) 2x4 1 STL 2024-01-02
Nikon Z Lens Holder 2x2 2 STL 2024-01-16
Nippers, Strippers, Pliers Rack 1x4,2x4,1x5 3 STL 2022-06-12
OpenSCAD Templates Varies 2 OpenSCAD 2022-09-26
Open Ended Holders 1x5 - 4x5 10 STL 2022-07-21
Paint Shelf 2x3, 3x3, 4x3 3 F3D + STL 2022-09-04
Paper Towel Roll 3x4 1 STL 2022-07-20
Parametric Bottle with Cap 1x1-4x4 7 STL,F3D 2022-09-26
Parametric Vase Mode Bins 1x1-3x3 6 STL,F3D 2024-01-18
Pelican 3310 Flashlight Holder 1x1 1 STL 2022-07-25
Pen, Pencil, Marker Holder 1x2 3 STL 2022-06-12
Phone Stand 2x2 1 STL 2022-07-01
Pic + Tweezers Rack 2x2 1 STL 2022-06-12
Pinecil Solder iron Holder 1x1 1 STL 2022-07-25
Bin - Vase Mode 1x4 1 Tinkercad 2022-12-06
Plain Bin 1x1-3x4 26 3MF 2022-06-12
Plain Bins 3x6 2 STL 2022-07-25
(Plain Bin) Dispenser lids 3x6 2 STL 2022-07-25
(Modified) Pliers Rack 2x2 - 2x4 2 AMF 2023-10-07
Posca Marker Holder 2x2-2x3 1 STL 2024-03-19
Post-It Stack Container 2x2 1 STL 2022-08-16
Prusa Pliers and Flat Cuts 1x1 1 3MF + STL 2022-09-04
Raspberry Pi Case 2x2 1 STL 2022-07-25
Raspberry Pi Pico Holder 2x1 1 STL 2022-09-04
Raspberry Pi Zero Holder 2x1 1 STL 2022-09-04
Ratchet Holder 1x4 1 STL 2022-09-26
Ratchet Screwdriver Holder 1x3 1 STL 2022-07-11
Ratchet + Socket Holders 1x3,1x4,1x5 5 STL 2022-07-19
Reinforced Economical Bins 0.5x0.5 to 7x7 1185 3MF 2022-08-26
Ryobi Quick Change Hobby Knife 1x1 2 STL,STP,F3D 2024-02-07
Ruler & Pen Pot 1x2 1 STL 2022-07-11
Ruler Holder 1x1 1 STL 2022-09-04
Screwdriver Rack 1x2 1 STL 2022-07-08
Screw Measure Tool 1x1 1 STL 2024-02-14
Sewing Needle Holder 1x2 1 STL,STEP,F3D 2023-10-07
ScrewUnit ? ? ? 2024-06-15
Screwfinity Unit 2U Large 3x5 1 STL,3MF,STP,OBJ,FBX 2024-06-15
Sharpie Holder 1x1 1 STL 2022-07-18
Sideless Bins 1-5x5 27 STL 2022-06-18
Slide-Up Drawer 2x1x2 2 parts STL 2022-09-04
Socket Holder ? ? OpenSCAD 2022-06-12
Socket Set Organizer for Husky 125-Piece Set 1x2 - 3x5 1 3MF,STEP 2023-10-15
Solder Flix & Soldering Iron Tip Cleaner 2x2 3 STL 2024-04-01
Solder and Wire Spool Holder 2x3 1 STL 2022-06-19
Solder Reel Stand 2x2 1 STL 2022-07-25
Small Part Sort and Storage 2x2 1 STL 2022-08-16
Spade Bit Holder 4x3 1 STL 2022-09-22
Spiralized Gridfinity Bins 1x1 1 STL 2023-03-21
Speed Square Holder 4x4 1 STL 2023-09-16
Spudger Holder 1x1 1 F3D + STL 2022-09-04
Stackable Citadel Paint Pot Storage 1x1-6x6 5 STL,F3D 2022-09-26
Starbond CA Glue Variety Pack 2x3 1 STL 2022-09-21
Sticky Note Holder 2x2 1 STL 2022-09-04
Storage Boxes 1x1-3x3 24 STL 2022-07-19
Superglue Bottle Holder 1x1,3x3 2 STL 2022-07-19
Swinger Trays 2x2 1 STL 2022-09-26
Swinging Drawer 3x3 2 STL 2022-09-04
Tabletop (Gaming) 1x1 3 STL 2022-09-04
Tap and Die Bins 1x3, 2x2 9 STL,3MF 2024-04-20
Tape Dispenser 1x2 1 3MF 2022-07-01
Tape Holder 3x3 1 STL 2022-09-04
Tarot Card Box 1x3, 2x3 4 STL 2022-06-12
Template with Mid-Air Holes 1x1 1 STL,F3D 2022-09-26
Testors Paint Jars 1x2 1 STL 2022-06-12
Threaded Insert Tips Holder 1x2 1 STL 2023-02-28
Tiered Bins 1x1 3 STL 2022-08-16
The One SD Card Holder 1x1 1 STL 2022-07-25
Tinkercad Blanks Varies 8 Tinkercad 2022-07-25
Toolbox Organizer (Ratchets and Sockets) 1x2-2x3 8 3MF 2023-12-26
Tweezers Box - Optimized 10x4 1 STP,STL 2024-04-01
Ultimate Battery Holder (AA, AAA, AAAA, 2032, LR44, A97, 18650, 9v) 3x5 1 STL 2022-07-25
USB & Micro SD Holder 1x1 1 STL 2022-06-12
USB and SD Card Holder 1x2 1 STL 2022-06-12
USB A & C holder 1x1,2x1 2 STP, STEP 2024-02-14
Vase Mode Single Box 1x1 4 STL 2022-06-12
Watch Band Bin 3x1 1 F3D,3MF,GCODE 2023-12-26
Watch Band Holder 2x3 1 STL 2022-09-06
Wera Imperial 950 Allen Key Holder 4x7 1 STL 2023-03-15
Wera Metric 950 Allen Key Holder 4x7 1 STL 2023-03-15
Wera Screwdriver Holder 1x3 1 STL 2022-07-01
Wiha Metric Nut Driver Holder 1x2 1 STL,F3D,3MF 2023-04-26
Wii Remote Bin 3x4 1 STL,3MF,STP,F3d 2024-03-19
Wire Spool Holder 4x1 1 STL/F3D 2022-07-25
Workbench Dremel Bit storage Remix 5x3 1 STL 2022-07-25
Xacto Holder 1x1 1 STL 2022-07-25
Xiaomi Wowstick 1F+ Holder 2x5 2 STL 2022-09-04
Ziggurat Storage Bin 3x3 1 STL 2022-09-04
Ziplock, Wrap, and Kitchen Extra Containers 2x3-2x8 30 STL 2024-06-03

Lids for Bins

Description Format Date Added
Lid 1x1 1
Lids 1x1-3x4 13
Lids with Handles 1x1-5x5 25
Parametric Lids 1x1-3x3 STL,F3D

Dashboard

Description Format Date Added
Gridfinity Dashboard Module for 8.8" 1920x480 Ultra-Wide Touch Screen and 3 M5Stack Dials STL,F3D 2024-02-13
Gridfinity Dashboard Module for Loupedeck Live STL,F3D 2024-02-13
Gridfinity Dashboard Module for Two M5Stack Dials STL,F3D 2024-02-13
Interface Plate for Dashboard Modules STL,F3D 2024-01-25
Dashboard Module for Stream Deck XL STL,F3D 2024-01-25
Dashboard Module for Stream Deck Plus STL,F3D 2024-01-25

More Dashboard Modules.

Adapters

Description Sizes Variants Format Date Added
Gridfinity Adapters 1x1 - 5x5 1 STL/F3D 2022-07-28
Height Adaptive Spacers various 30 STL 2022-07-25

Templates

Description Sizes Variants Format Date Added
Base Template with Improved Holes and Weight Slots 1x1 2 STEP,F3D,STL 2022-10-26
Template with Mid-Air Holes 1x1 1 3MF,F3D 2022-10-26

Everything Else

Description Sizes Variants Format Date Added
Gridfinity Legs 1x1 10 STL 2024-01-21
Gridfinity Carousel 1x5 1 STL 2024-01-09
Gridfinity Carousel, Motorized 1x5 1 2024-06-03
Gridfinity Lifted 1x2 - 2x4 27 OpenSCAD,STL 2022-10-26
Mega-Gridfinity ToGo Box 4x4 1 STL 2022-06-17
Toolbox (Parametric) 5x3 7 elements STL 2022-07-25
Pegboard Gridfinity 2x2 4 STL 2022-12-17
Rugged Case "Light" 5x4 3 STL 2024-06-03
Modular Expandable Storage Box 2x3, 4x5, 4x7 3 STL 2023-01-16
Modular Rack System for Gridfinity Drawers 5x5 1 STL, STP 2024-01-23
Gridfinity Label Maker - 1 EXE, STL, PDF 2023-07-17
Gridfinity Storage Box 4x3 - 7x6 6 STL, F3D 2023-08-31
Gridfinity Storage Box - Prusa Mini 3x3 1 3MF 2023-10-03
Gridfinity Rugged Storage Box (parametric) (source) 2x4 - 6x6 + Customizable Many OpenSCAD, STL 2024-02-14
Gridfinity Master Collection 1x1-7x7 633 STL,OpenSCAD 2024-03-21

Online Generators

Articles

Videos

Other Resources
